Infrared Night Vision CMOS Security Camera | 1000TVL | 0 Lux | 36 IR LEDs | DC 12V | 1/50–1/100,000 Shutter | SNR >48dB | Indoor & Outdoor

Infrared Night Vision CMOS Security Camera — 1000TVL | 0 Lux | 36 IR LEDs | DC 12V | Indoor & Outdoor Surveillance

Monitor your property day and night with this infrared night vision CMOS security camera. The CMOS image sensor delivers 1000TVL (TV lines) of analogue resolution — sharp, detailed video for clear identification of faces, vehicles, and events in the monitored area. The 0 Lux minimum illumination rating means the camera can capture clear video in complete darkness using its 36 infrared IR LEDs — no ambient light required for night monitoring. The wide shutter speed range (1/50 to 1/100,000 second) handles both low-light night scenes and bright daylight conditions without overexposure. SNR >48dB provides a clean, low-noise image signal. DC 12V/750mA power supply. Suitable for indoor and outdoor security monitoring applications.

Key Features

• 1000TVL CMOS Sensor — Sharp Analogue Resolution: The CMOS (Complementary Metal-Oxide Semiconductor) image sensor delivers 1000TVL (TV lines) of analogue resolution — the high end of standard analogue CCTV resolution, providing sharp, detailed video for clear identification of faces, licence plates, and events in the monitored area. CMOS sensors provide excellent light sensitivity, low power consumption, and fast readout speeds compared to older CCD sensors — making them the preferred sensor type for modern security cameras
• 0 Lux Minimum Illumination — True Night Vision: The 0 Lux minimum illumination rating (at F1.2 aperture) means the camera can capture clear video in complete darkness using its 36 infrared IR LEDs — no ambient light required for night monitoring. The infrared LEDs illuminate the scene invisibly to the human eye, providing clear black-and-white night vision footage without alerting subjects to the camera’s presence. Essential for overnight security monitoring of entrances, car parks, warehouses, and outdoor areas
• 36 × Φ5mm IR LEDs — Wide-Area Infrared Illumination: 36 infrared LEDs (5mm diameter each) provide wide-area infrared illumination for night vision coverage across the camera’s field of view. The high LED count ensures even, consistent infrared illumination without dark spots or uneven coverage at the edges of the frame. Verify the effective IR night vision range (metres) with supplier — the LED count and arrangement determine the maximum useful night vision distance
• 1/50–1/100,000 Shutter Speed — Day & Night Adaptability: The wide shutter speed range from 1/50 second (low-light, night scenes) to 1/100,000 second (bright daylight, fast-moving subjects) allows the camera to adapt automatically to a wide range of lighting conditions — from complete darkness to bright outdoor sunlight — without overexposure or motion blur. The fast maximum shutter speed (1/100,000s) freezes fast-moving subjects such as vehicles and running individuals for clear identification
• SNR >48dB — Clean, Low-Noise Image: Signal-to-noise ratio (SNR) greater than 48dB provides a clean, low-noise image signal — reducing the visual noise (grain) that degrades image quality in low-light conditions and makes it difficult to identify subjects in the footage. Higher SNR values indicate cleaner, clearer images with less noise — important for security footage where image clarity is critical for identification and evidence purposes
• DC 12V / 750mA — Standard CCTV Power: Powered by DC 12V / 750mA — the standard power supply voltage for analogue CCTV cameras, compatible with standard CCTV power supplies, distribution boxes, and DVR power outputs. The 12V DC standard ensures compatibility with existing CCTV infrastructure and makes the camera easy to integrate into new or existing security systems. Verify the camera’s lens type (fixed / varifocal), field of view (degrees), and housing type (dome / bullet / box) with supplier

Specifications

• Image Sensor: CMOS
• Resolution: 1000TVL
• Minimum Illumination: 0 Lux / F1.2
• IR LEDs: 36 × Φ5mm
• Shutter Speed: 1/50(1/60) – 1/100,000 second
• SNR: >48dB
• Power: DC 12V / 750mA
• Weight: 432g

In the Box

• 1 × Infrared Night Vision CMOS Security Camera
• Accessories (verify exact contents with supplier)

⚠️ Note: This is an analogue CCTV camera (1000TVL) — requires a compatible analogue DVR or monitor with BNC/RCA input for recording and viewing. Not an IP/WiFi camera — does not connect directly to a smartphone or network without additional equipment. Verify the camera’s lens focal length (mm) and field of view (degrees) with supplier. Verify the housing type (dome / bullet / box) and IP weatherproof rating with supplier before outdoor installation. Verify the effective IR night vision range (metres) with supplier. DC 12V power supply not included — verify with supplier.
